Engine Cranks But No Start !

[Angelggx]

My Ford Bronco 2022 2.3L Outerbanks cranks but the engine won't start.

My car is a salvage vehicle and was completely rebuilt, including the main engine wiring harness, as it had broken or damaged wires. The car ran perfectly for 1-2 months without any issues. It was when I switched the driving mode to SPORT that the car started having misfire warnings on the dashboard. The engine began to sputter and lose power.

I was able to get home, but smoke was coming from the upper left side of the car where the PCM is located. I have pulled out the PCM and inspected the wire harness to the PCM and there are no visible signs of burnt damage to the cables and the PCM itself. PCM hasnt been open yet. There are no oil or coolant leaks, which makes me think it's an electrical problem.

The spark plugs and ignition coils were replaced, and the car started again. I tested it around the block, and it failed again. It won't start again. The entire fuel pump in the tank was replaced, and it still won't start.

Any ideas on what to look for on Forscan? What PDI's and values should I look for? Any help or intake is appreciated.


Below is my latest Forscan DTC report.


-----------------------------------------------------------------------------------------------------
Latest scan using Forscan , I am aware of parking sensor DTCs as front sensors are missing.

===OBD2_PCM DTC None===
Successful DTC reading, no error codes found

Module: On Board Diagnostic II (PCM)

===END OBD2_PCM DTC None===

===PCM DTC None===
Successful DTC reading, no error codes found

Module: Powertrain Control Module

===END PCM DTC None===

===SIMA DTC None===
Successful DTC reading, no error codes found

Module: Switch Input Module A

===END SIMA DTC None===

===ABS DTC None===
Successful DTC reading, no error codes found

Module: Antilock braking system

===END ABS DTC None===

===PSCM DTC None===
Successful DTC reading, no error codes found

Module: Power Steering Control Module

===END PSCM DTC None===

===BdyCM DTC B1D00:15-48===
Code: B1D00 - Left Low Beam

Additional Fault Symptom 15):
- Circuit Short To Battery Or Open

Status (-48):
- Previously Set DTC - Not Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC
- Test not complete

Module: Body Control Module

===END BdyCM DTC B1D00:15-48===

===BdyCM DTC B1D01:15-48===
Code: B1D01 - Right Low Beam

Additional Fault Symptom 15):
- Circuit Short To Battery Or Open

Status (-48):
- Previously Set DTC - Not Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC
- Test not complete

Module: Body Control Module

===END BdyCM DTC B1D01:15-48===

===BdyCM DTC B14E5:55-0A===
Code: B14E5 - Left Front Enhanced Exterior Lighting System

Additional Fault Symptom 55):
- Not Configured

Status (-0A):
- DTC Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC

Module: Body Control Module

===END BdyCM DTC B14E5:55-0A===

===BdyCM DTC B14E7:55-0A===
Code: B14E7 - Right Front Enhanced Exterior Lighting System

Additional Fault Symptom 55):
- Not Configured

Status (-0A):
- DTC Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC

Module: Body Control Module

===END BdyCM DTC B14E7:55-0A===

===GWM DTC None===
Successful DTC reading, no error codes found

Module: Gateway Module A

===END GWM DTC None===

===AWD DTC None===
Successful DTC reading, no error codes found

Module: All Wheel Drive Module

===END AWD DTC None===

===BCM_C DTC None===
Successful DTC reading, no error codes found

Module: Body Control Module C

===END BCM_C DTC None===

===APIM DTC None===
Successful DTC reading, no error codes found

Module: Accessory Protocol Interface Module

===END APIM DTC None===

===SODR DTC None===
Successful DTC reading, no error codes found

Module: Side Obstacle Detection Control Module - Right

===END SODR DTC None===

===SODL DTC None===
Successful DTC reading, no error codes found

Module: Side Obstacle Detection Control Module - Left

===END SODL DTC None===

===IPMB DTC None===
Successful DTC reading, no error codes found

Module: Image Processing Module B

===END IPMB DTC None===

===ATCM DTC None===
Successful DTC reading, no error codes found

Module: All Terrain Control Module

===END ATCM DTC None===

===OCS DTC None===
Successful DTC reading, no error codes found

Module: Occupant Classification System Module

===END OCS DTC None===

===TCU DTC None===
Successful DTC reading, no error codes found

Module: Telematic Control Unit Module

===END TCU DTC None===

===RTM DTC None===
Successful DTC reading, no error codes found

Module: Radio Transceiver Module

===END RTM DTC None===

===PDM DTC None===
Successful DTC reading, no error codes found

Module: Passengers Door Control Unit

===END PDM DTC None===

===DDM DTC None===
Successful DTC reading, no error codes found

Module: Drivers Door Module

===END DDM DTC None===

===RCM DTC None===
Successful DTC reading, no error codes found

Module: Restraint Control Module

===END RCM DTC None===

===PAM DTC B1B36:31-2A===
Code: B1B36 - Right Front Outer Sensor

Additional Fault Symptom 31):
- No Signal

Status (-2A):
- DTC Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC

Module: Parking Aid Module

===END PAM DTC B1B36:31-2A===

===PAM DTC B1B38:31-2A===
Code: B1B38 - Right Front Inner Sensor

Additional Fault Symptom 31):
- No Signal

Status (-2A):
- DTC Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC

Module: Parking Aid Module

===END PAM DTC B1B38:31-2A===

===PAM DTC B1B40:31-2A===
Code: B1B40 - Left Front Outer Sensor

Additional Fault Symptom 31):
- No Signal

Status (-2A):
- DTC Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC

Module: Parking Aid Module

===END PAM DTC B1B40:31-2A===

===PAM DTC B1B42:31-2A===
Code: B1B42 - Left Front Inner Sensor

Additional Fault Symptom 31):
- No Signal

Status (-2A):
- DTC Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC

Module: Parking Aid Module

===END PAM DTC B1B42:31-2A===

===HVAC DTC None===
Successful DTC reading, no error codes found

Module: Heating Ventilation Air Conditioning

===END HVAC DTC None===

===ACM DTC None===
Successful DTC reading, no error codes found

Module: Audio Control Module

===END ACM DTC None===

===SCCM DTC None===
Successful DTC reading, no error codes found

Module: Steering Column Control Module

===END SCCM DTC None===

===IPC DTC None===
Successful DTC reading, no error codes found

Module: Instrument Panel Control Module

===END IPC DTC None===

===IPMA DTC U0420:86-AF===
Code: U0420 - Invalid Data Received from Power Steering Control Module 'A'

Additional Fault Symptom 86):
- Signal Invalid

Status (-AF):
- DTC Present at Time of Request
- Malfunction Indicator Lamp is On for this DTC

Module: Image Processing Module A

Freeze Frame #1:
-EVENT_TIME: 60184273 s (Wed Dec 03 11:13:22 2025) - Event time
-TOTAL_DISTANCE: 83285 km - Total Distance
-MODULE_VOLTAGE: 12.5 V - Control Module Voltage
-OUTDOOR_TEMPERATURE: 26 °C - Outside temperature
-ECU_POWER_SUPPLY: 12.3 V - ECU Power Supply Voltage
-ECU_INTERNAL_TEMPERATURE: 30 °C - ECU Internal Temperature
===END IPMA DTC U0420:86-AF===

Sponsored



[VirginiaHeritage]



[Angelggx]

I should’ve seen that one coming.. YES IT HAS GAS IN IT.



[Brian_B]

Just checking out the DTC codes - I'd start by looking at the wiring to the headlights and the sensors up in the front bumper.



[Ninjak]

Well, I did not look at codes, but engine turning but not cranking, even on newer engines, relates to fuel, spark, and combustion.

You may have replaced the fuel pump, but are the injectors giving enough fuel? Are the coils sparking? Does it start and die? Are there any leaks in the hoses?

Reading thru what you have written, Smoke says there is a leak somewhere. If not a burning, then perhaps a vacuum? Maybe from vapors? If it could be electrical, then perhaps the spark is failing?

I am more of an old-school mechanic, but this still applies to newer engines. Maybe something in the ECU is throwing the timing off, as it does not ignite correctly. Or I would look to fuel.



[CitrusBronco]

That smoke means something burned up. You don't just get smoke by itself. Start sniffing and opening up the harness.



[Angelggx]

Here is a video of trying to start the car. I notice the PDI for IGNITION SWITCH reads error. Is this due to the car not starting? You can also see the fuel pump fluctuating. Any other PDIs I can check to streamline an issue?



[Ducati1098]

Can you pull up FRP (fuel rail pressure)?



[SledDog30]

Question. Are the parts OEM or amazon? It could make a difference. But letting the magic smoke out is never a good sign. Did you have the negative battery cable disconnected when you did all this?

I would find what was burning before you go much further. Try and monitor any of the sensors associated with start up. Coils, crank sensor, fuel pump, fuel pressure if forscan can do so.

Your DTCs, to me, indicate a wiring issue. Double check any and all wiring.



[Angelggx]

Can you pull up FRP (fuel rail pressure)?

Here are the FRP values when cranking



[Angelggx]

Question. Are the parts OEM or amazon? It could make a difference. But letting the magic smoke out is never a good sign. Did you have the negative battery cable disconnected when you did all this?

I would find what was burning before you go much further. Try and monitor any of the sensors associated with start up. Coils, crank sensor, fuel pump, fuel pressure if forscan can do so.

Your DTCs, to me, indicate a wiring issue. Double check any and all wiring.

All parts that were used on the rebuild are from a ford dealership. Where the smoke came from is still unknown. I have inspected any visible wire harness and there are no signs of visible damage to the sleeves.

Im leaning to the idea that the smoke came from my PCM module. Which still hasn't been opened to inspect. Its still able to communicate but an issue can still be present, correct?



[Ducati1098]

Here are the FRP values when cranking

Okay well that rules out fuel system to the injectors, but doesn’t necessarily rule out the injectors actually firing.

PM me your VIN, I want to see if I can check connected data.



[UncleBrad]

Just checking out the DTC codes - I'd start by looking at the wiring to the headlights and the sensors up in the front bumper.

Exactly! I would look for a problem in the harness leading to the headlights (and any other related endpoint):

Code: B1D00 - Left Low Beam

Something was drawing a lot of current ahead of the fuses, so I would look for a crimp or compromised insulation. You didn't mention how it smelled. Did it have a burnt plastic smell, or a hot semiconductor smell?



[Valhalla]

Find where the smoke came from. Find the short. Electrical issues are tedious to find but relatively easy to repair.



[Angelggx]

I finally have an update. After some parts were replaced ( Fuel Injectors and Gas Tank Pump assembly) It ended up being the Crankshaft sensor. Once the sensor was replaced the car turned on.

Heres the tricky part, the car turned on several times and when left on for testing without moving (Aprox 30min ) the car shut off and wont turn on again. We are back at crank but no start.
