Clutch slipping when in boost

Is the South Bend Clutch worth it

  • Yes, if you're going to offraod you need this upgrade

  • No, doesn't truly improve offrad reliability

  • Who knows, nobody has been dumb enough to pay for it


Results are only viewable after voting.

Tonka13

Base
New Member
First Name
J
Joined
Mar 6, 2025
Threads
1
Messages
2
Reaction score
0
Location
US
Vehicle(s)
2022 Bronco
Your Bronco Model
Base
22 Bronco Base 7MT Sasquatch 25k Miles

I was driving on the freeway and downshifted to make a pass when the Bronco went into a reduced power mode. I pulled over and turned the truck off then back on and the issue went away. About a week later I was going up a hill and when the Bronco started using boost the same thing happened. This time I noticed that the engine speed increased at a faster rate then the truck accelerated before it went into the reduced power mode. I connected to get the code read and confirmed the code specified clutch slippage. I can recreate the issue anytime now just by being in gear at pretty much any cruising speed and then trying to accelerate in the same gear. When boost comes on the clutch will start to slip. The odd thing is that it only happens in this specific scenario or when going uphill. Otherwise the Bronco can be driven normally with no issue. As long as there is no agressive acceleration, the clutch engages and shifts normally.

I've driven MT my whole life, I have never experienced a clutch go out like this. In my experience, a worn clutch would have noticeable pedal degredation and difficulty engaging gears at low speeds such as starting from a stop. I'm worried this may not be a worn clutch, but a more complex issue. I'm planning to have the clutch removed next week to inspect and potentially replace but wanted to see if anyone else has had this experience.

I have taken it offraod in the past and when in the sand or snow, where you have to ride the clutch a bit to keep from stalling, I have noticed a burning smell afterwards. Nothing that in my experience would indicate a complete failure, and only noticeable when standing outside the vehicle.

I remember Ford initially was not planning to offer the MT with the Sasquatch pkg, but eventually did. I had to wait an extra year on my order because of this. I'm wondering if the OEM clutch is just not up for the stress put on it when offroading. I've been looking into a replacement, but options appear to be limited. The only one I can find is the offerings from Southbend Clutch. Based on my limited research, I was looking at their endurance clutch for a more reliable offroading application. They also offer a daily and drag version, though I can't imagine why someone would be drag racing a Bronco, if that's truly what that version is for. Has anyone had experience with this product? I'm wondering if the performance and reliability is worth the premium price, or should I go with an OEM clutch replacement and just hope the original was a defective part.
Sponsored



Brian_B

Big Bend
Well-Known Member
First Name
Brian
Joined
Sep 14, 2023
Threads
60
Messages
8,240
Reaction score
14,587
Location
Central CA
Vehicle(s)
'23 BB 4dr 7MT, '22 BSport OBX, '87 B-II XL
Your Bronco Model
Big Bend
Clubs

Hmm.

I don't think having SAS makes a big difference on the clutch.

And I agree with you on worn clutch - and that this doesn't sound like that. It sounds more like you may have got oil or some other contaminate on the clutch surface, or the flywheel surface has got degraded signficantly. Will be interested to see pics of the clutch and flywheel once you get it out.

I don't have any input on aftermarket clutches though, hopefully someone else with more experience can chime in on that.


mpeugeot

Outer Banks
Well-Known Member
First Name
Mark
Joined
May 14, 2021
Threads
24
Messages
9,148
Reaction score
18,927
Location
Texas
Vehicle(s)
97 Ferrari F355, 11 Ford F-150, 21 OBX 2D
Your Bronco Model
Outer Banks
If you have to replace the clutch anyway, I guess that I would put in an upgraded clutch, but definitely not a Kevlar one - but an clutch that will tolerate being slipped and has increased clamping force.


albart

Member
Joined
Apr 27, 2025
Threads
0
Messages
5
Reaction score
5
Location
East Tenn
Vehicle(s)
2024 2 door
Your Bronco Model
Undecided
From what i've read and my experiences coming from a world of shit boxes with manual transmissions. With the clutch being a dual-mass flywheel, it might be worth considering a single-mass flywheel while it's apart, due to the cost of a new dual-mass unit.
I did read (someone on here perhaps) had taken the plunge and swapped in a single mass flywheel, but it messed up the clutch pedal "feel".
something to consider.
Watching the thread for pics. at 5500mi on mine right now. Shifts great.


Lcubed

Badlands
Well-Known Member
First Name
l
Joined
Jul 27, 2020
Threads
24
Messages
2,017
Reaction score
3,070
Location
UsA
Vehicle(s)
VW golf r, 2023 ManBadSquatch
Your Bronco Model
Badlands
Clubs

22 Bronco Base 7MT Sasquatch 25k Miles

I was driving on the freeway and downshifted to make a pass when the Bronco went into a reduced power mode. I pulled over and turned the truck off then back on and the issue went away. About a week later I was going up a hill and when the Bronco started using boost the same thing happened. This time I noticed that the engine speed increased at a faster rate then the truck accelerated before it went into the reduced power mode. I connected to get the code read and confirmed the code specified clutch slippage. I can recreate the issue anytime now just by being in gear at pretty much any cruising speed and then trying to accelerate in the same gear. When boost comes on the clutch will start to slip. The odd thing is that it only happens in this specific scenario or when going uphill. Otherwise the Bronco can be driven normally with no issue. As long as there is no agressive acceleration, the clutch engages and shifts normally.

...

I have taken it offraod in the past and when in the sand or snow, where you have to ride the clutch a bit to keep from stalling, I have noticed a burning smell afterwards. Nothing that in my experience would indicate a complete failure, and only noticeable when standing outside the vehicle.
sounds like you glazed the clutch pads


Sponsored

crenca

Big Bend
Well-Known Member
First Name
Chris
Joined
Nov 4, 2024
Threads
24
Messages
1,382
Reaction score
2,234
Location
Southern New Mexico
Vehicle(s)
2016 Sequoia, 2012 Tundra, 2024 Sasquatched 2.3L 7M 4Door Bronco
Your Bronco Model
Big Bend
About a week later I was going up a hill and when the Bronco started using boost the same thing happened. This time I noticed that the engine speed increased at a faster rate then the truck accelerated before it went into the reduced power mode. I connected to get the code read and confirmed the code specified clutch slippage. I can recreate the issue anytime now just by being in gear at pretty much any cruising speed and then trying to accelerate in the same gear. When boost comes on the clutch will start to slip. The odd thing is that it only happens in this specific scenario or when going uphill. Otherwise the Bronco can be driven normally with no issue. As long as there is no agressive acceleration, the clutch engages and shifts normally.

I've driven MT my whole life, I have never experienced a clutch go out like this.
This is a clutch that is worn out. It’s still creating enough friction under normal light-to-medium torque situations, but when your engine is in peak mid range boost there’s enough torque to get it to slip.

You’re just gonna have to replace it. I don’t know anything about these aftermarket clutches. I got my clutch too hot in an off-road situation where I thought I was in 4H but was in fact in 4A, I was using reverse quite a bit. Some odor and the pedal got soft. Only happened once however, I figured I shaved maybe 10 K of life off a clutch that should be good for 150 K…we will see.


Sparkie

Heritage
Well-Known Member
Joined
Nov 15, 2024
Threads
0
Messages
322
Reaction score
399
Location
Massachusetts
Vehicle(s)
Sold all my cars to buy the Heritage Bronco
Your Bronco Model
Heritage
Clubs

22 Bronco Base 7MT Sasquatch 25k Miles
...
I have taken it offraod in the past and when in the sand or snow, where you have to ride the clutch a bit to keep from stalling, I have noticed a burning smell afterwards. Nothing that in my experience would indicate a complete failure, and only noticeable when standing outside the vehicle.
...
Yikes!
Riding the clutch while in Crawl Gear to "smell" level!? -- You are far more adventurous than me and my Bronco!

Any off-road trail where I thought I needed to ride the clutch in "C" was my indicator the trail would be taking me on "the road to ruin" for my Bronco or for me.


crenca

Big Bend
Well-Known Member
First Name
Chris
Joined
Nov 4, 2024
Threads
24
Messages
1,382
Reaction score
2,234
Location
Southern New Mexico
Vehicle(s)
2016 Sequoia, 2012 Tundra, 2024 Sasquatched 2.3L 7M 4Door Bronco
Your Bronco Model
Big Bend
Yikes!
Riding the clutch while in Crawl Gear to "smell" level!? -- You are far more adventurous than me and my Bronco!

I too was perplexed about his admitted driving style, and saying "have never experienced a clutch go out like this.", as it is after all the usual way.

Then I thought of my brother-in law. I rode with him once in his low powered Honda (small displacement 4 that is NA) and he road the clutch consistently - even using it to hold the vehicle on inclines at red lights. When I asked him the last time he replaced the clutch he said "never", and he had something like 80k on the thing!?! He also admitted he never driven a manual truck or high torque car, only compacts with NA 4's.

Maybe Honda makes clutches that can withstand this sort of driving style regularly?? I bet the majority of folks who get into a manual Bronco under a certain age (say 40) have only driven manuals in low powered compacts, as all high torque trucks/cars went auto only by 2000's (besides high powered Euro exotics, small number of cadillacs/corvettes, etc.).

Whatever the case, you can't drive the (boosted high-torque 4 cylinder) Bronco like that, the clutch is not engineered for it...


dgorsett

Big Bend
Well-Known Member
Joined
Apr 3, 2019
Threads
25
Messages
4,993
Reaction score
9,981
Location
colorado
Vehicle(s)
F250, Mustang, Explorer
Your Bronco Model
Big Bend
Yikes!
Riding the clutch while in Crawl Gear to "smell" level!? -- You are far more adventurous than me and my Bronco!

Any off-road trail where I thought I needed to ride the clutch in "C" was my indicator the trail would be taking me on "the road to ruin" for my Bronco or for me.
Thanks for broaching the subject, I didn't want to be accused of being a hater and my Bronco has an auto so no room to talk but I will anyway :) . Previous 4x4s with manuals usually had granny gear but not always, seldom if ever smelled burning clutch. Use that crawler gear and low range. The poster running dunes from the middle east asking about removing upper gear limits in 4L in an auto knows.


Sponsored

Brian_B

Big Bend
Well-Known Member
First Name
Brian
Joined
Sep 14, 2023
Threads
60
Messages
8,240
Reaction score
14,587
Location
Central CA
Vehicle(s)
'23 BB 4dr 7MT, '22 BSport OBX, '87 B-II XL
Your Bronco Model
Big Bend
Clubs

Then I thought of my brother-in law. I rode with him once in his low powered Honda (small displacement 4 that is NA) and he road the clutch consistently - even using it to hold the vehicle on inclines at red lights. When I asked him the last time he replaced the clutch he said "never",
Clutch life is all about torque. They can live for quite a while in on an idle engine at a stop light. Start trying to do burn outs all the time though…

Throw out bearing is a different story though


0ne

Base
Well-Known Member
First Name
Nate
Joined
Jun 1, 2022
Threads
6
Messages
996
Reaction score
1,099
Location
CO
Vehicle(s)
Flex
Your Bronco Model
Base
sounds like you glazed the clutch pads
On a slippery/loose surface rev to boost level in neutral, drop clutch and put some tooth back in the clutch surface 🤷‍♂️


JC2DR

Base
Well-Known Member
First Name
Joseph
Joined
Oct 22, 2022
Threads
5
Messages
107
Reaction score
159
Location
Maine
Vehicle(s)
Bronco Base 2dr 2.3 7speed
Your Bronco Model
Base
I have close to 50,000 miles on the original clutch. Mild off-road to be sure but no issues. Occasionally, after a trip with a lot of stop and go traffic there’s a bit of smell but it doesn’t last.


BadlandsA51

Badlands
Well-Known Member
First Name
Craig
Joined
Aug 17, 2022
Threads
1
Messages
465
Reaction score
562
Location
Kansas
Vehicle(s)
23 Badlands, Sasquatch, Lux Pkg, 72 Ranchero GT
Your Bronco Model
Badlands
Yeah, riding the clutch to the point of smelling it doesn’t happen very many times before the clutch is toast. It’s hard to imagine that being necessary if transmission was in crawl gear and transfer case was in 4 low. You can walk beside one of these running 2500 RPM in low/low.
